AN32-17000 Hollow Hydraulic Torque Wrench

Ideal for high-torque bolt removal in large machinery equipment.

Features

Torque repeatability ±3%, optimal torque-to-weight ratio
360° swivel hose connection design
Integrated reaction arm, durable and reliable
Slim design suitable for tight and complex applications
Double-acting, high speed, large angle
Expandable with metric and imperial hex adapters and sockets
Aerospace-grade aluminum-titanium alloy combined with high-strength alloy steel for toughness and light weight
Quick-change plug-in design with easy adapter replacement

REQUEST A QUOTE REQUEST A DEMO

Product Information

MODEL SPECIFICATION
DOWNLOADS
Accessories

COMPARE MODELS

Compare

Model	Max. torque	Min. torque	Power head model	Work head model	Length 1	Height 1	Height 2	Width 1	Width 2	Weight
Model	N.m	N.m			mm	mm	mm	mm	mm	kg
AN32-2500	2500	250	AN1-25	AN2-25	160	133	102	32	50	2
AN32-5000	5000	500	AN1-50	AN2-50	246.3	159	124	42	64	5
AN32-10000	10000	1000	AN1-100	AN2-100	302	195	160	53	75	9.5
AN32-17000	17000	1700	AN1-170	AN2-170	355	221	182	64	95	17
AN32-23000	23000	2300	AAN1-230	AN2-230	390.5	264.5	215	73	97	23
AN32-40000	40000	3500	AAN1-415	AN2-415	456	304.5	255	85	120	38
