DC31-400 Hydraulic Core Drill

Ideal for drilling various types of rail tracks and I-beams in flammable and explosive environments.

Features

High drilling precision and easy to install and remove
Rail clamp equipped with a self-locking mechanism
Explosion-proof hydraulic motor
Equipped with automatic water-cooling system
Clamping device offers secure locking and accurate center positioning
Customizable clamps available upon request.
Fast drilling speed with high accuracy

Product Information

MODEL SPECIFICATION
DOWNLOADS
Accessories

COMPARE MODELS

Compare

Model	Hand drilling size	Station drilling size	Motor output	No load speed	Torque	Flow rate	Oil inlet	Weight	Tool kit
Model	mm	mm	kW	rpm	N.m	l/min	In	kg
DC31-150	100	150	2.5	300/700/1350	90/56/29	10-20	1/2	9.5	DC31-150K
DC31-300	100	300	2.8	300/700/1350	90/56/29	10-20	1/2	12	DC31-300K
DC31-400	100	400	3.0	380/900/1800	70/45/25	10-20	1/2	13	DC31-400K
