Home> Products> Drilling Tools> Core Drill

DC21-400 Pneumatic Core Drill

Ideal for drilling and coring rock, reinforced concrete, asphalt concrete, walls, ore, and other non-metallic hard materials.

Features

Three-speed gearbox for adjustable drilling speed
Explosion-proof pneumatic motor for hazardous environments
Durable aluminum alloy body
Adjustable bracket for drilling angled holes from 0° to 90°
Dual-switch design for enhanced safety
D-shaped handle for improved comfort during operation

REQUEST A QUOTE REQUEST A DEMO

Product Information

MODEL SPECIFICATION
DOWNLOADS
Accessories

COMPARE MODELS

Compare

Model	Hand drilling size	Station drilling size	Motor output	No load speed	Torque	Working pressure	Air inelt	Weight	Tool kit
Model	mm	mm	kW	rpm	N.m	Mpa	In	kg
DC21-100	100	100	1.6	400/900/1600	49/31/16	0.4-0.6	3/4	9.0	/
DC21-150	100	150	2.5	300/700/1350	90/56/29	0.4-0.6	3/4	9.5	DC21-150K
DC21-300	100	300	2.8	300/700/1350	90/56/29	0.4-0.6	3/4	12	DC21-300K
DC21-400	100	400	3.0	380/900/1800	70/45/25	0.4-0.6	3/4	13	DC21-400K
